Shimano Stella FK Fishing Reel 2022

The new generation of STELLA sets an unmatched performance standard with a number of upgrades for the ultimate fishing experience. True to its rich history, Infinity Evolution continues.

The new Stella features the following major technology upgrades for 2022. Infinity Cross achieves overwhelming gear durability through a revised drive and pinion gear design with improved surface area contact and meshing. Infinity Loop creates a precise winding pattern which drastically reduces friction as line leaves the spool, resulting in exceptional casting performance. Infinity Drive greatly decreases frictional resistance, increasing power transmission and torque when winding under heavy loads. An Anti-Twist Fin has been installed near the line roller to maintain line tension and prevent line wrapping around the spool in an uneven manner. While Dura Cross, a revolutionary new drag washer design, provides a substantial increase in durability while providing smooth consistent drag performance.

In addition to this, the Stella still continues to feature the super durable cold forged Hagane Gear, Micromodule II gearing, Silent Drive and X-Ship for smooth transmission and light winding. To ensure on water performance X Protect water resistant technology still features and the Long Stroke Spool design provides maximum casting performance.

Models

STL1000FK

Capacity Dia (mm-m): 0.25/90
Gear Ratio: 5:1:1
Retreive Per Crack (CM): 64
Bearings: 12+1
Drag Power(kg): 3
Weight (g): 165

STL2500HGFK

Capacity Dia (mm-m): 0.25/160
Gear Ratio: 5:8:1
Retreive Per Crack (CM): 86
Bearings: 12+1
Drag Power(kg): 9
Weight (g): 210

STLC3000XGFK

Capacity Dia (mm-m): 0.25/210
Gear Ratio: 6:4:1
Retreive Per Crack (CM): 94
Bearings: 12+1
Drag Power(kg): 9
Weight (g): 210

STL4000XGFK

Capacity Dia (mm-m): 0.30/180
Gear Ratio: 6:2:1
Retreive Per Crack (CM): 101
Bearings: 12+1
Drag Power(kg): 11
Weight (g): 260

STLC5000XGFK

Capacity Dia (mm-m): 0.35/175
Gear Ratio: 6:2:1
Retreive Per Crack (CM): 101
Bearings: 12+1
Drag Power(kg): 11
Weight (g): 260

Features

INFINITY XROSS

Advancements in manufacturing technology and gear tooth design improve the surface contact and meshing between the drive gear and pinion gear. This revolutionary design efficiently distributes the load placed on the gear tooth surface across a wider area to prevent damage from stress points while significantly improving overall gear durability.

INFINITY LOOP

Advancements in the internal structure and design extend the spool's oscillation to enable the spool to move up and down at an extremely low speed. This technology creates a precise winding pattern with less overlap that significantly reduces friction as the line leaves the spool during a cast. The result is smooth and exceptional casting performance, especially of light lures.

INFINITY DRIVE

The Infinity Drive structure is a more advanced version of the conventional X-SHIP structure that created exceptionally light winding. The main shaft, which had previously been supported by the pinion gear, is now supported by a new and unique low-friction bushing that significantly decreases frictional resistance. In addition, the main shaft has undergone a proprietary surface treatment and special processing to drastically reduce rotational torque, constructing a reel that can actively wind even under heavy loads.

ANTI TWIST FIN

The flexible polymer fin is installed near the line roller. This maintains line tension to reduce sagging and prevents the line from falling off the bottom of the spool or wrapping around the spool in an uneven manner.

New AR-C Spool Shape

The new AR-C spool shape improves line management by modifying both the shape and angle of the spool ring as well as the drag knob to significantly lessen the risk of line looping or fouling. Utilizing technology with a proven track record in Stella SW, a proprietary barrier coat is applied to the spool ring for strong abrasion resistance to maintain its original smooth condition.

DURA CROSS

Constructed to enhance overall durability, this revolutionary drag washer incorporates cutting-edge materials woven in a unique pattern compared to conventional drag washers. Without sacrificing a smooth drag feel, this new material is greater than 10x more durable for improved drag performance.
